42
Pump Technology Ltd. can specify and
supply a wide range of
MACERATOR, SEWAGE, DRAINER &
WASTE WATER PUMPING SYSTEMS.
56 Youngs Industrial Estate, Aldermaston, Berks. RG7 4PW
Tel: 01189 821555 Fax: 01189 821666
E-mail:
Web Site:
Typical Installations
z
Wetrooms where the drainage down
pipe is remote from the shower and
gravity drainage is not an option.
z
Loft conversions where height
constraints apply and it is not desirable
to raise the floor level.
Whale has expertise in this specialist
area since 1995. The reliability of the
Dry-Deck system gives peace of mind
to the home owner.
The easy drainage solution for wet rooms in difficult locations
Dry-Deck 20 is a well proven and trusted product from Whale that provides the answer for
many conversion and renovation projects.
The range of shallow pumped gulleys allows installation of walk-in showers and wet rooms in
locations where this previously would not have been possible.
Dry-Deck 20
Concrete floor with tiled surface
For concrete floors, the shower base is let into
the concrete screed. When the pipework has
been installed, the shower base can be
bedded down to sit level with the existing
floor. The final floor covering can then be
applied (vinyl or tiled).
Timber floor with vinyl covering
The minimal 22mm thickness of this
pre-formed shower base is ideal for most
timber floors. To fit the base, the floor boards
are removed. When the drainage and the
pipework have been installed,the base can
be permanently fixed to the joists.
The remaining floor must finish level
with the Aqua-Dec’s edges in preparation for
the floor covering.
Typical wet floor options
The following details feature the ‘Aqua-Dec’
wet-room floor former which has a 22mm
depth profile. It is ideal for restricted depth
showers and locations requiring the Dry-
Deck 20 system.
Features and Benefits
z
Flow rate of up to 20 ltrs/min.
z
Flow rate adjusts to changes in shower
flow rate.
z
Almost silent when running.
z
Valves prevent odours escaping.
z
Easily concealed components.
