HIGH LEVEL ALARMS
for SEWAGE & WASTE WATER
PUMPING SYSTEMS
These units are designed for
connection to a 240V supply circuit
The alarm buzzer has a minimum
volume of 80 dBA (at 1m distance).
A rechargeable battery is fitted in case
of mains electricity supply failure.
PTL1A (SIDE MOUNTED FLOAT) USED WITH A FLOOR
MOUNTED WASTE WATER SYSTEM e.g. DRAINMAJOR -
DRAIN-KING
The float mechanism provided must be attached through the side
of the GRP tank and positioned in an area away from the inverts
from sinks, dishwashers, glasswashers etc. to prevent ingress of
water inadvertently actuating the horizontal float switch mechanism.
PTL1B (TOP MOUNTED FLOAT) USED WITH A FLOOR
MOUNTED WASTE WATER SYSTEM e.g.
DRAINMASTER.
The float mechanism provided must be attached through the
indent point situated under the end cover on the top of the tank.
PTL1C (NON MERCURY SWITCH FLOAT) USED WITH
BELOW GROUND SEWAGE OR WASTE WATER
PUMPING SYSTEM e.g. PUMPMATIC.
A float and weight is provided to activate the High Level Alarm.
We recommend that the float is securely attached to the
discharge pipework at a higher level than the activation level of
the
automatic float switch of the pump.
PTL1D (REMOTE ALARM) USED WITH FLOOR
MOUNTED SEWAGE SYSTEMS e.g. EFFLU MAXI,
EFFLU MIDI
These systems have volt free contacts on both the single and
dual pump versions. They are designed to be wired into the main
Control Panel of Pump Technology Floor Mounted Waste Water
and Sewage Pumping Systems.
Pump Technology Ltd. can specify and
supply a wide range of
MACERATOR, SEWAGE, DRAINER &
WASTE WATER PUMPING SYSTEMS.
