Pump Technology Ltd. can specify and
supply a wide range of
MACERATOR, SEWAGE, DRAINER &
WASTE WATER PUMPING SYSTEMS.
56 Youngs Industrial Estate, Aldermaston, Berks. RG7 4PW
Tel: 01189 821555 Fax: 01189 821666
E-mail:
Web Site:
PUMPMATIC 300
Packaged Sewage Pumping System
Due to a policy of continuous product improvement we reserve the right to alter specifications without notice.
SECTIONAL PLAN OF GRP TANK
TOP GUIDE MOUNTING
BRACKET FOR
INSTALLING AND
REMOVING PUMPS
Internal 1250 mm
Inlet
Size as
required
Submersible
Sewage Pumps
Discharge
Spigot
Pumps on Self
Locating Quick
Release couplings
Access Frame &
Cover with Clear
Opening of
1000 x 775
5 Tonne GLVW
SECTION A-A
Ground Level
635 mm
2300 mm
1300 mm
Maximum
Level
Control
Floats
PUMP SELECTED
TO MEET
CUSTOMER
REQUIREMENTS
FOR INFORMATION
ONLY
PUMP MAY DIFFER
FROM ONE
ILLUSTRATED
Tank INVERT & DISCHARGE
are set at a
STANDARD HEIGHT
Discuss any variations
BEFORE ORDERING
Discharge pipework must
be UPVC Class ‘C’ or ‘D’
Solvent weld or MDPE pipe
black as shown
NOTE:
Inlets can be
located to
customer
requirements!
38 tonne, double
sealed, lockable,
recessed covers
available.
