Pump Technology Ltd. can specify and
supply a wide range of
MACERATOR, SEWAGE, DRAINER &
WASTE WATER PUMPING SYSTEMS.
56 Youngs Industrial Estate, Aldermaston, Berks. RG7 4PW
Tel: 01189 821555 Fax: 01189 821666
E-mail:
Web Site:
PUMPMATIC 200
Packaged Sewage Pumping System
Due to a policy of continuous product improvement we reserve the right to alter specifications without notice.
Inlet
Size as required
Submersible
Sewage Pump
Discharge Spigot
Pump on Self Locating
Quick Release couplings
Access Frame & Cover
with Clear Opening of
600 x 600 5 Tonne
GLVW
2300 mm
1800 mm
Maximum
SECTION A-A
635 mm
Ground Level
SECTIONAL PLAN OF GRP TANK
TOP GUIDE MOUNTING
BRACKET FOR
INSTALLING AND
REMOVING PUMPS
Internal 1000 mm
Cable Duct
83 mm
PUMP SELECTED
TO MEET
CUSTOMER
REQUIREMENTS
FOR INFORMATION
ONLY
PUMP MAY DIFFER
FROM ONE
ILLUSTRATED
Tank INVERT & DISCHARGE
are set at a
STANDARD HEIGHT
Discuss any variations
BEFORE ORDERING
Discharge pipework must
be UPVC Class ‘C’ or ‘D’
Solvent weld or MDPE pipe
black as shown
NOTE:
Inlets can be
located to
customer
requirements!
38 tonne, double
sealed, lockable,
recessed covers
available.
