The EFFLU MAXI
TM
120 twin pump
Sewage disposal units with
tough power that can be
relied on!
APPLICATIONS
These systems have a large capacity 350 Ltr. tank
and are designed specifically for commercial and
industrial situations where toilets are to be used
by a number of people and where domestic
macerators / pumping systems are totally unsuitable.
The capital cost of purchasing a floor-mounted sewage
pumping station will be more economical than the
maintenance cost of using domestic pumping systems.
The
EFFLU MAX
I 120 range is ideal in situations where
several toilets have to be fitted in one location (together
with hand basins, urinals, kitchens and utility sinks).
The toilets can be manifolded together and brought into
the pumping station, which can be sited on the same
level, lower level or on the floor below.
EFFLU MAXI
systems pump in 4" discharge pipework
using non-clogging pumps with large free
passage that ensures freedom from blockage.
The EFFLU MAXI 120 will pump to a vertical head of
6-18 metres depending on the system used.
“EFFLU MAXI” 120 TWIN
PACKAGED SEWAGE
PUMPING UNIT WITH
FREEFLOW VORTEX PUMP
DISCHARGE PIPEWORK:
4" uPVC Class C or D
solvent weld (or copper, iron etc. as required)
VENT:
70mm vent to AIR/ATMOSPHERE is required
(a DURGO / AIR ADMITTANCE VALVE
MUST NOT BE USED)
see
Microvent
page 36 if
venting to air is a problem.
A
- Centre Inlet, variable
between 560 & 700mm
H
- 800mm
W
- 910mm
D
- 1010mm
H
D
A
W
13
Pump Technology Ltd. can specify and
supply a wide range of
MACERATOR, SEWAGE, DRAINER &
WASTE WATER PUMPING SYSTEMS.
