16
Type
Supply
Voltage
Motor Rating kw
input
Motor Rating kw
output
Current Amperes
RPM
80 twin
1-phase
230
1.55
1.09
6.9
1442
80 twin
3-phase
400
1.30
1.10
2.8
1451
80/51 twin
3-phase
400
2.20
1.70
3.9
1405
80/52 twin
3-phase
400
3.00
2.20
5.1
1363
Type
Supply
Voltage
Motor Rating kw
input
Motor Rating kw
output
Current Amperes
80D 3-phase
400
1.25
87
2.2
1390
80E 1-phase
230
1.55
1.09
6.9
1440
Type
80 E Single
80 D Single
Tank Capacity
litres
Floor to Centre
Inlet mm
Inlet Flange
Weight kg Discharge Size Vent Pipe mm
50
180
DN100
64
3" or 4"
70
50
180
DN100
64
3" or 4"
70
Due to a policy of continuous product improvement we reserve the right to alter specifications without notice.
The
EFFLU MAXI:
Consists of a Polyethylene tank complete with a discharge
non return valve and couplings for all invert, discharge &
vent connections including reflux (non return valve).
Both systems have a Control Panel with overload relay,
alarm device, high level alarm and volt free contacts for
remote alarm.
The twin pump unit is equipped with a Control Panel giving
duty changeover, duty assist and duty standby on the
pumps. Install in a dry area.
The
EFFLU MAXI
comes complete with a one year
warranty. In the unlikely event of technical
difficulties, please ring:
Pump Technology Limited on
01189 821555
See also:
EFFLU GRINDER
Single Pump Sewage Disposal unit. Pages 17 & 18
TECHNICAL DATA
EFFLU MAXI 80 Single
EFFLU MAXI 80 Twin
Also available with 250mm floor to centre inlet if required
Also available with 315mm floor to centre inlet if required
MOUNTING ARRANGEMENTS
EFFLU MAXI 80
SINGLE
PUMP
MOUNTING ARRANGEMENTS
EFFLU MAXI 80
TWIN
PUMP
RPM
Type
Tank Capacity litres Floor to Centre Inlet
mm
Inlet Flange Weight
kg
Discharge Size
Vent Pipe
mm
80 D or E twin
100
250
DN100
140
3" or 4"
70
80/51 D twin
100
250
DN100
140
3" or 4"
70
80/52 D twin
100
250
DN100
140
3" or 4"
70
For Flow Rates, see Page 35
For Flow Rates, see Page 35
